200 DGU

The Velfac 200 DGU range of windows is a stylish and sophisticated window system fitted with double glazing. Available in glazed windows, casement doors and sliding casement doors.

Velfac 200 Energy Windows

Product Details

The Velfac 200 DGU is the double glazing offering from Velfac, consisting of a slimline composite frame with a solid timber core and a powder coated aluminium capping giving you the best of both worlds including the soft homely feel of timber internally and the hard wearing exterior of aluminium. The timber core gives enhanced energy efficiency when compared with all aluminium and upvc windows. Designed for the European market there are a wide range of opening options within this window system giving you complete design flexibility.

All Velfac windows come completer with a 12 year warranty and are manufactured from FSC certified timber ensuring quality and responsible forestry. With a huge range of colours and finishes your new windows can be customised to suit you and your home perfectly. All units have uniform sightlines, whether fixed, opening or motorised, and recessed installation also delivers a 'floating' sash, adding to the contemporary finish.



Technical specifications

  • Outward opening elements in wood / aluminium
  • SBD accredited
  • Extensive test programme
  • Uw value: down to 1.36
  • Glazing options: 24mm double glazing
  • A comprehensive 12 year warranty

Opening Funcitons

The Velfac 200 Energy range is a window system with triple glazing, in a modern and classy design. It’s available in a variety of opening functions.

Sidehung Window

Side-Guided Window

Fixed Casement

Top-Guided Window
Glass to Glass Corner
Tophung Reversible Window
Casement Door 1-Leaf
Tophung Window

Casement Door, 2-leaf

Sliding Casement Door, 1 Leaf

Sliding Casement Door, 1 Leaf

Sliding Casement Door, 2 Leaf

Sliding Casement Door, 2 Leaf

Bottomhung Window

Sidehung Window

200 Energy Fittings & Accessories

The versatile 200 Energy window range can further be adapted to you and your family. Whatever your requirements – child safety, ventilation or automation – the 200 Energy DGU can be tailored to your specific needs.

Espagnolette, standard

Espagnolette with lock

Espagnolette with child-lock

Ventilation Position

Handle operated brake

WindowMaster motor for Natural Ventilation

Concealed 90⁰ hinges for windows and casement doors

180⁰ hinge

Circular catch handle

External cup handle for external fitting

Restrictor with ventilation position

Sidehung Window

Lockable restrictor (160mm or 270mm)

Click vent

Acoustic trickle vent

Colours, materials and surface finish

VELFAC windows, casement doors and sliding casement doors are made of hard-wearing materials that require a minimum of maintenance.

Carefully selected materials and paint finishes ensuring maximum protection by utilising the best surface treatments.

Classic K7 Ral Colours

Choose from over 200 classic K7 RAL colours in gloss 77 or gloss 30. Due to deviations in screen colours the displayed colours and finishes will differ from reality, so ask to see a colour sample before specifying.

Anodized Colours

Another external finish is the unique anodized aluminium available in shades of silver and bronze. Anodizing aluminium gives a protective and ornamental finish, a natural process where share differences may occur. * Colour deviations my occur.

VELFAC Granite, textured colours

With a unique rough cut granite like texture the granite finish is available in various shades of black and grey and is an alternative finish to standard powder coating.

External colours and surface finishes

The external aluminium capping is a highly durable surface and should never need repainting, only cleaning a few times a year, or as needed.

As shown above several surface treatment options are available:

  • Matt powder coating in a classic K7 RAL colour, gloss 30
  • Glossy powder coating in a classic K7 RAL colour, gloss 77
  • ‘VELFAC Granite colours’ which is a textured finish, that looks and feels like rough-cut granite
  • Anodized surface finish in bronze, silver or black

Glazing bars consist externally of an aluminium profile in the same colour as the sash. The glazing gaskets are black.

 Internal colours and surface finishes

The wood is surface is treated using a coloured paint or clear lacquer.

Choose from our 30 different standard RAL colours or clear lacquer so that the grain of the wood can be seen. Approx. 170 special colours among the classic K7 RAL colours are available at an extra cost.
However the most popular finishes are white (RAL 9010), black (RAL 9005) or clear internal lacquer finish to reveal the beauty of the wooden frame.

For the final finish, only water-based materials that do not release toxic substances into the room afterwards.

VELFAC 200 has burglary resistant internal glazing beads. Please select the colour that best matches the frame finish: white (RAL 9010), grey (RAL 7035) or black (RAL 9005).

Glazing bars are internally white, grey or black, as the glazing bead.
